Description
THE NEXT GENERATION X i SERIES, NOW WITH MORE INTELLIGENCE AND INDUSTRIAL BRAWN
Advancing the legacy of their industry-leading Xi Series predecessors, the ZT610 and ZT620 combine rugged durability and exceptional performance on a user-friendly, future-ready platform. These next-generation workhorses are designed to help you navigate the rapidly evolving business technology landscape. So, whether you're concerned about growing production line demands, increasing operational complexities, integrating disparate systems or controlling investment costs, ZT600 Series Industrial Printers have you covered today - and for years to come.
A Leap Forward in Industrial Thermal Printing
Zebra's industrial printers are well known for their durability, fast print speed, long life span and unparalleled reliability. The ZT610 and ZT620 build on that legacy, with the most advanced, comprehensive feature sets of any Zebra stationary printer series. To keep your critical operations running smoothly across a broad range of applications, ZT600 Series printers provide:
24/7 Reliability in the Harshest Environments
ZT600 Series printers are built to withstand the most demanding industrial conditions, virtually eliminating operational downtime due to printer failure. Plus, they meet your high-volume production needs, day in and day out, with superior print quality and speed across the widest range of applications.
Micro-Consistent Printing for Top-Quality Micro Labels
Featuring highly precise registration and print line adjustment, the ZT610 offers 600 dpi printing for labels as small as 3 mm for applications like circuit boards, chips and miniature components-all without wasting expensive media due to improper printing.
User-Friendly Setup, Use, Maintenance & Troubleshooting
Intuitive Link-OS® applications and user-friendly design features streamline everything from deployment to daily use to routine maintenance. Compatibility with other printing systems and technologies simplifies integration and management, while onboard sensors, diagnostics and help resources guide troubleshooting so users don't have to call in support for every minor issue.
Highly Adaptable, Future-Ready Platforms
The last thing you need is a new piece of technology that will be obsolete in just a couple of years. That's why the ZT600 Series was engineered with the future in mind-from an adaptable design that allows communications, media handling and other upgrades in the field, to compatibility with SOTI and AirWatch device management software, to intuitive Link-OS applications that simplify updates and reconfiguration as needed.
Features
- Print Methods: Thermal transfer and direct thermal printing
- Construction: Metal frame and bi-fold metal media cover with enlarged clear viewing window
- Side-loading supplies path for simplified media and ribbon loading
- Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality
- Communications: USB 2.0, high-speed, RS-232 Serial, Gigabit Ethernet, Bluetooth 4.0
- Highly visible color display that turns red when the printer is in an error state allows operators to determine printer status from a distance
- Simplified icon menu navigation system categorizes settings into logical groups of functions
Specifications :
Memory
|
Standard Memory |
1 GB |
Miscellaneous
|
Energy Star |
Yes |
Power Description
|
Power Source |
AC Supply |
Interfaces/Ports
|
USB |
Yes |
|
Serial Port |
Yes |
Network & Communication
|
Bluetooth |
Yes |
|
Ethernet |
Yes |
Physical Characteristics
|
Weight (Approximate) |
22.68 kg |
|
Height |
395.7 mm |
|
Width |
268.2 mm |
|
Depth |
505 mm |
Media Types & Handling
|
Maximum Roll Diameter |
203 mm |
|
Media Type |
Die-cut Label |
|
Black Mark |
|
|
Continuous Label |
|
|
Notch |
|
|
Maximum Label Width |
114 mm |
General Information
|
Product Type |
Direct Thermal/Thermal Transfer Printer |
|
Manufacturer Part Number |
ZT61043-T0P0100Z |
|
Manufacturer Website Address |
|
|
Manufacturer |
Zebra Technologies Corporation |
|
Product Model |
ZT610 |
|
Product Name |
ZT610 Industrial Printer |
|
Product Series |
ZT600 |
|
Brand Name |
Zebra |
Technical Information
|
Application/Usage |
Industrial |
|
Maximum Print Width |
104 mm (4.09") |
|
Recommended Use |
Label Print |
|
Maximum Mono Print Speed |
356 mm/s |
|
Mobile Device Printing |
Yes |
|
Print Color Capability |
Monochrome |
|
Maximum Print Length |
3.30 m |
|
Maximum Print Resolution (dpi) |
300 |
